Fujipoly Sarcon® Extreme-performance Thermal Pad – 0.5mm 13mk/W

5 out of 5 based on 1 customer rating
(1 customer review)

$ 14.25

  • SKU: GR80A-0H-50GY
  • Brand: Fujipoly

60 in stock

Description

The new 13 Watt Sarcon®  Thermal Gap Filler Pads are highly conformable and high heat-conducting gel materials in a versatile sheet form. They easily fit and adhere to most all shapes and sizes of components, including protrusions and recessed areas. This significantly increases surface contact with a heatsink and improves cooling performance.

Specification:

  • Thermal conductivity:  ASTMD 5470 test 13.0 W/m°K (No compression Hot Disk test 8.0 W/m°K)
  • Withstand Voltage: 15 kV/min
  • Volume Resistivity: 1.0×1011 MΩ•m
  • Thickness: 0.5mm ± 0.1mm
  • Sheet size: ~ 100x50mm
  • Surface: sticky surface
  • Useful Temperature: -40 to +150 ℃
  • Colour: Light Gray
  • Made in Japan

Handling:

  • Keep pads in the sealed package to protect from dirt and drying up.
  • It is recommended to use the material in up to 30% of the compression ratio.
  • It is recommended to compress the material with an equal ratio on the whole surface. Partial excessive stress may also result in excessive silicone oil exudation.
